1、 External reasons


① Charger data cable


When charging with a non original charger data cable, the voltage is unstable, which can cause the screen to malfunction and jump. It is recommended to disconnect and replace the charger data cable.



② Screen protector film


Poor quality tempered film may affect the touch effect. It is recommended to tear off the film and check if the sensitivity is restored.



③ Water or dirt on hands



You can try wiping the screen of your phone with a tissue to remove any oil stains that may cause touch drift.



④ There is static electricity present


Static electricity on mobile phones can also be uncontrollable. In this case, you can lock the screen and charge the phone for ten minutes to solve the problem.



2、 System reasons


① Software issues


Determine whether it is a certain software or all software fixed area touch failure. If a single software is not sensitive in that area, it may be due to software issues. If all software has the same location touch failure, it is a screen problem and needs to be repaired.



② Too many backend software


Opening the software in the background is likely to cause the mobile phone to get too laggy, and the screen is not sensitive. Try to close the background running software.



③ System issues


If there are many applications installed on the mobile system and the phone configuration is not high, it is easy to cause insufficient phone resources, so this phenomenon may also occur. It is recommended that you try to restore the factory settings or flash the phone.



④ Crash or false crash


It can be resolved by turning off the screen or restarting the phone.



3、 Screen related reasons


Touch failure caused by the screen itself: such as dropping the phone, loosening the LCD screen cable after liquid ingress, and corrosion of the touch IC. These hardware damages can cause the screen to drift and touch failure.



How about it, have you learned how to judge?



It should be noted that the hardware failure of the screen itself involves the repair of internal parts of the phone, which cannot be repaired by an individual. It is necessary to seek professional maintenance personnel for repair and replacement. Do not disassemble or repair it yourself to avoid losses.

011. Analysis of Mobile Screen Technology
1.1 Overview of LCD and OLED
LCD relies on external light sources, while OLED can emit light on its own; The two principles are fundamentally different.
1.2 LCD Screen Technology
LCD screen, also known as Liquid Crystal Display, has become a mature technology after a long period of development and is widely used in various types of mobile phone screens. At present, screen technologies such as TFT, IPS, and SLCD can all be classified as LCD screens. Among them, TFT, as a general term for LCD panels, was once the mainstream of early LCD screens. Although its display effect was mediocre, its cost was low, so it was still adopted by many low-end models.IPS screens, often referred to as "SuperTFT" in the industry, are an upgraded form of LCD screens that essentially still belong to the category of TFT screens. Compared to ordinary TFT screens, IPS screens have a more transparent display effect, bright colors, and a wider viewing angle, reportedly even reaching a viewing angle range of nearly 180 °. SLCD, also known as "Super LCD", belongs to a higher level of LCD screen technology, and its excellent display effect and good color reproduction ability have won widespread praise.
1.3 OLED Display Technology
Compared with LCD screens, the biggest feature of OLED screens is the self luminous display technology of pixels, which makes OLED screens more outstanding in display effects and become the mainstream direction of future screen technology development. At present, AMOLED screens dominate the OLED field, and Samsung, as a leader in mastering core technologies, has achieved increasingly accurate color reproduction in its products, with significant improvements in color cast compared to earlier products. Super AMOLED， As an important product of Samsung in the OLED display market, it is widely praised for its high color saturation and vivid display effects, especially in terms of color performance. Samsung's Super AMOLED screen is considered a leader in the industry.
1.4 [Introduction to 120Hz Flow Rate Screen]
Recently, mobile phone manufacturers have launched 120Hz streaming screens, which brings us a brand new visual experience through technological innovation. The flow rate screen, with its high refresh rate of 120Hz, significantly surpasses the refresh rate of traditional 60Hz mobile phone screens. In fact, the refresh rate of 120Hz flow rate screens has been improved, and optimized circuit components have been used to achieve higher screen refresh rates.

In fact, the perception ability of the human eye is often misled. For example, the common 24FPS frame rate in movies, which plays 24 frames per second, sacrifices 1/24 of a second of motion detail despite the use of motion blur technology to make the images appear coherent. This trade-off may be acceptable for movies, but in games, each frame is a static image rendered in real-time. If it is still presented at 24 frames per second, it will result in disjointed actions. The high refresh rate of the flow screen helps to improve the performance of dynamic images, bringing users a smoother visual experience.

Overall, mobile screen technology is developing towards higher refresh rates and better display effects. LCD occupies a place in the market with its mature technology and diversity, while OLED is gradually becoming mainstream with its excellent display effects and self luminous advantages. With the continuous innovation of technology, future mobile phone screens will definitely bring us more surprises and better user experience

Collaborative innovation, industry university research collaboration to forge the technological highland of "Chinese screen"

As a leading Chinese enterprise in the AMOLED field, Vishino has always been driven by technological innovation and has joined forces with Tsinghua University and domestic material manufacturers to launch technological breakthroughs in the field of OLED material devices. After years of research and development, the company has successfully overcome key technological bottlenecks and released the fourth generation pTSF material device system. This system has been comprehensively upgraded from three dimensions: luminous efficiency, color gamut coverage, and device lifespan. It not only achieves purer color presentation, lower energy consumption, but also extends screen lifespan. It has officially been put into mass production and commercial use, adding core chips to the competition of "Chinese screens" in the global market.

Technological breakthrough, redefining AMOLED performance benchmark

In the development process of OLED technology, how to simultaneously achieve high efficiency, long lifespan, and high color purity of OLED has always been an important research issue. Compared to traditional OLED devices, the fourth generation pTSF device technology introduces multiple energy transfer modes, ultimately emitting light from a fluorescent emitter, achieving 100% internal quantum efficiency utilization. Moreover, the exciton lifetime of devices using pTSF technology has achieved a leap from microseconds to nanoseconds, suppressing exciton annihilation and quenching processes within the device, thereby achieving higher efficiency and longer lifetime, as well as higher color purity.

As the "barometer" of the global display industry, the SID exhibition in 2025 saw Vishino launch high-efficiency pTSF device products and wide color gamut pTSF device screens globally, which attracted widespread attention in the industry for their performance. Data shows that screens equipped with high-efficiency pTSF devices reduce power consumption by over 12% and increase lifespan by 15% compared to traditional devices. Taking a smartphone with a daily battery life of 10 hours as an example, installing this screen can increase usage time by an additional 1.2 hours, effectively solving the pain point of "fast screen power consumption" in mobile devices. The wide color gamut pTSF device body has achieved breakthroughs in color reproduction, covering DCI-P3 color gamut (>99.5%) and Adobe RGB color gamut (>99.5%), with color accuracy reaching professional design level, meeting the needs of professional scenarios such as image creation and graphic design, while reducing energy consumption by more than 6% and increasing lifespan by 20%. At present, high-efficiency pTSF devices have completed mass production and begun to be applied in various mobile electronic devices in batches.

The technological breakthrough of Weixinnuo cannot be separated from the support of the industry university research collaborative innovation system. As a pioneer in China's OLED industry, the technological roots of Weixinnuo can be traced back to the OLED project team of Tsinghua University in 1996- it was this early technological exploration that accumulated a solid research and development foundation for the company. As of now, Weixinnuo has applied for over 20000 OLED related patents, with invention patents accounting for up to 89%. The patented technology covers the entire industry chain, including materials, devices, processes, and equipment, forming a complete technical protection system. In terms of industry standards and innovative achievements, Vicino has broken the monopoly of foreign enterprises: it is a Chinese enterprise that * formulates international standards for flexible displays, has won more than 20 global "*" innovative technologies and applications, more than 50 national "first" breakthroughs, and has also won the "first prize of the the State Technological Innovation Award" of the display industry *, becoming the "synonym" of China's display technology innovation.

In November 2024, Professor Duan Lian from Tsinghua University gave a keynote speech on the improvement of OLED performance at the screen technology press conference held by Weixinnuo. The two sides had in-depth exchanges on the research and development details and application scenarios of pTSF technology, further deepening the cooperation between industry, academia and research. In fact, the breakthrough of pTSF technology is the result of long-term cooperation between the two parties. The advantages of Tsinghua University in the field of basic research complement each other's experience in industrialization, accelerating the process of technology from the laboratory to the market. Practice has proven that the advantages of pTSF technology in key indicators such as color purity, efficiency, and lifespan not only validate the effectiveness of industry university research collaborative innovation, but also provide a replicable model for the technological upgrade of "Chinese screens".

The mass production and commercialization of the fourth generation pTSF material device system by Visionor is not only an important leap forward for the company's own development, but also promotes the key transformation of "Chinese screens" from "technology *" to "product *", which is of milestone significance in the global display industry. This achievement marks that "Made in China" has completely shed its identity as a "follower" in the AMOLED field, and has become a "leader" in the industry through independent innovation. In the future, it will continue to promote technological changes in the global display industry, allowing "Chinese screens" to shine even brighter in the global market.

Preliminary Exploration of ProMotion Technology: The Secret of Adaptive Refresh Rate


ProMotion， This name itself contains the dual meanings of "professional" and "dynamic", indicating a major innovation in Apple's screen display technology. In short, ProMotion technology is a mechanism that can automatically adjust the screen refresh rate based on the current display content, with refresh rates ranging from a minimum of 10Hz to a maximum of 120Hz. This means that when you swipe the screen to browse web pages, play games, or watch high frame rate videos, the screen can present incredibly smooth visual effects with a refresh rate of up to 120Hz; When displaying statically or performing low-intensity operations, such as reading e-books, viewing photos, or in standby mode, the screen will lower the refresh rate to a more suitable level to save power.



Why choose adaptive refresh rate?


The reason why Apple introduced adaptive refresh rate technology in the iPhone 13 Pro series is due to profound considerations and user demand insights.



Improving user experience: Firstly, a high refresh rate screen can bring a smoother visual experience. For gamers, a high refresh rate of 120Hz means lower latency and finer transitions, taking the gaming experience to the next level. For daily users, whether sliding the screen, scrolling through web pages, or switching applications, they can feel an unprecedented sense of smoothness. However, if the phone always maintains a 120Hz refresh rate, it will not only consume a lot of electricity, but may also cause problems such as device overheating due to unnecessary performance output, affecting the overall user experience.


Optimizing energy management: As stated by Apple, one of the core advantages of adaptive refresh rate is its excellent energy management capabilities. Mobile screens are one of the largest energy sources in smartphones, especially when the brightness is high and the refresh rate is fixed at a high level. Through ProMotion technology, the iPhone 13 Pro series can dynamically adjust the refresh rate according to actual needs, effectively avoiding unnecessary energy waste. For example, when users are still viewing pictures or documents, the screen refresh rate can be reduced to 10Hz or even lower, significantly reducing battery consumption and extending battery life. This is undoubtedly a huge blessing for users who frequently go out and have high requirements for mobile phone battery life.


The combination of intelligence and efficiency: The implementation of ProMotion technology relies on Apple's powerful hardware and software integration capabilities. It requires seamless collaboration between screen driver chips, operating systems, and various applications to ensure real-time and accurate refresh rate adjustments. This intelligent adjustment mechanism not only reflects Apple's technological innovation, but also its commitment to pursuing the ultimate user experience. The algorithm predicts the user's behavior and adjusts the refresh rate in advance, so that each screen refresh is just right, which not only ensures the smoothness of visual effects, but also realizes the efficient use of energy.


Challenges and Solutions Behind Technology


Implementing adaptive refresh rate is not an easy task, as it requires the phone to find a perfect balance between hardware design, software development, and user experience. Apple has invested a significant amount of research and development resources in this regard, overcoming multiple technical challenges



Hardware upgrade: The iPhone 13 Pro series is equipped with more advanced display driver chips, which have stronger data processing capabilities and lower power consumption, providing a hardware foundation for fast and accurate refresh rate adjustment.
Software optimization: The iOS system has been deeply optimized to ensure that the system and third-party applications can fully utilize the advantages of ProMotion technology. Developers need to update their applications to adapt to display effects at different refresh rates, which requires Apple to provide detailed development guidelines and technical support.


User experience considerations: When designing ProMotion technology, Apple fully considered the differences in user perception. For example, the change in refresh rate between fast and slow swiping needs to be smooth enough to avoid giving users a sense of abruptness. This requires fine tuning and extensive user testing.


Impact on the industry and future prospects


Apple's introduction of ProMotion technology in the iPhone 13 Pro series not only enhances the competitiveness of its own products, but also has a profound impact on the entire smartphone industry. On the one hand, it has promoted the innovation of screen technology, prompting other manufacturers to accelerate their research and development pace in adaptive refresh rate technology; On the other hand, it has also raised consumers' expectations for the refresh rate of mobile phone screens, making high refresh rate and adaptive adjustment a standard feature of high-end smartphones.



Looking ahead to the future, with the continuous advancement of technology, adaptive refresh rate technology will become more mature and its application scenarios will become more extensive. For example, combined with AI and machine learning technology, mobile phones can more intelligently predict the user's next operation, adjust the refresh rate in advance, and further improve the user experience. Meanwhile, with the popularization of technologies such as 5G and AR/VR, adaptive refresh rates will leverage their unique advantages in more fields, bringing unprecedented interactive experiences to users.



In short, the ProMotion adaptive refresh rate technology in the Apple iPhone 13 Pro series is another important milestone for Apple in pursuing the ultimate user experience. It not only demonstrates Apple's leading position in technological innovation, but also sets a new benchmark for the entire smartphone industry, indicating the direction of future smartphone screen technology development. With the continuous evolution of technology, we have reason to believe that future smartphones will serve our daily lives in a more intelligent, efficient, and energy-saving way, allowing the light of technology to illuminate every corner.

Don't panic, the first step in self-study is to "line out" the screen

'Screen out' often means that the internal screen is damaged, so it's better to do it yourself instead of wasting money. Taking S15Pro as an example, the entire screen replacement process is broken down into 7 key nodes, each step accompanied by real-life photos, and following along can save a lot of maintenance costs.

02
Removing the back cover: The glass material needs to be 'translated'

2.1 ◇ First, cut open the double-sided tape, and then lift the cover in parallel
Lightly scratch along the border with a thin card, loosen the double-sided tape completely, and then move it as a whole. Avoid breaking it hard at 90 °, otherwise the back cover will instantly break into a "puzzle".



2.2 ◇ Remove the protective cover and battery
After removing the back cover, unscrew all the fixing screws around the body without missing a single screw; After removing the protective cover, disconnect the battery and power off the motherboard to avoid short circuits during installation.

03
Take the small board: first disconnect the cable and then take the screw

3.1 ◇ Loosen the display cable and charging port
Gently loosen the speaker and display cable interface, and there is also a straight screw on the top of the small board. After removing it, all cables can be pulled out.

3.2 ◇ Remove the card tray and protect the red dust-proof adhesive
Use tweezers to grip the card holder and gently shake it out; Use a leaf shaped pick to lift the small red leather circle next to it to prevent it from hooking onto the wiring when disassembling the screen.

04
Dismantling old screen: Blade+8+1 combination method

4.1 ◇ Cut open the sealant and apply 8+1 drops of solubilizing aid
Stick the blade tightly around the screen, cut off the sealant first, and then drip a small amount of 8+1 solvent to soften the glue for easy separation.

4.2 ◇ Card stitching, slow work produces fine work
The nail is stuck in the gap, and the card is slowly pushed along the edge. After all the double-sided tape is scraped loose, the entire screen can be removed.

05
Clean up residual adhesive and apply UV glue, and apply sealant to the middle frame

5.1 ◇ Special UV double-sided adhesive for cranks is put into use
Clean up all the old adhesive on the middle frame, apply UV double-sided adhesive specifically for the crankshaft, and apply a circle of sealant around the edges. The amount should be small rather than large - if the adhesive seeps out, it will create bubbles on the new screen.

5.2 ◇ Installing a new screen: align first and then press down
After inserting the cable and aligning the top, gently press down to ensure that the double-sided tape is fully adhered to the middle frame; Push on the battery and perform a power on self-test. If the touch and display are normal, proceed to the next step.

06
Reinstall the small board: plug the charging port first

Before putting the small board back in, first insert the charging port into the hole and fix it, then fasten all the cables in sequence, and finally reinstall the battery - the appearance of the startup logo indicates that the hardware is ready.



07
Upper protective cover, rear cover, and sealant

7.1 ◇ Tighten all screws in place
The speaker, charging port, and small board screws have all been reset; Clean up the residual adhesive on the protective cover and back cover, and then apply special sealant.

7.2 ◇ Cover and flatten, installation completed
Align the back cover with the buckle and lightly press it to fit. If the fingerprint and power button rebound normally, it means the whole machine has been restored. Power on test of various functions, no "wires" on the screen, sensitive touch, normal sound - great success!
