1、 Why is the screen of an iPhone malfunctioning and jumping

1) The touch screen is broken (such as encountering greasy or magnetic environments).
2) The motherboard is leaking electricity. 3、 The battery is aging and damaged.

Generally speaking, the third possibility is the highest, and choosing to replace the battery can solve the problem of iPhone jumping.

2、 How to solve the malfunction and jumping of the iPhone 5s touch screen:

1) When users encounter screen malfunction while using their mobile phones, they can long press the home button while the screen is locked to enable voice control function. Then at this point, it is said that players can choose to play a song and then select the touch function to restore it. We can wait for a while and then we will find that the touchscreen issue has been fixed.


2) Users can also wait until their phone runs out of battery, and the phone will enter an automatic shutdown state. At this time, users can charge the phone and then restore touch screen operation after turning it on.

3) Users can connect their iPhone 5s to iTunes and upgrade their iPhone 5s to the latest version of the iOS system. (jailbroken users need to be aware that they cannot directly upgrade their iOS version on iTunes)

4) Users can also choose to double-click the home button, and then we will exit all programs running in the background, which is also a solution to screen failure.

5) Users can long press the power button on their phone and then hold down the home button to return to the home screen. This is also a solution to screen malfunction.




3、 IPhone 6/6 Plus touch screen malfunction? Solution to screen malfunction

1）. The first thing to do is to restart the iPhone and simultaneously press the "sleep/wake" button (also known as the power button) and the Home button until you see the Apple logo displayed on the screen.
2）. Some users solve this problem by selecting "Settings" - "General" - "Reset" - "Reset All Settings" in sequence. Users need to re-enter their password, change their wallpaper, and reset their Touch ID, but their data will not be deleted.


3）. Users who encountered iPhone 6/6 Plus touchscreen malfunction were able to solve the problem by restoring factory settings, but all information on the phone will be lost, so users need to back up important data in advance. Afterwards, users may need to set up their iPhone 6 like a new phone, and some users claim that restoring backed up data from iTunes or iCloud will cause this problem to occur again.
There are also some available methods that everyone can try:

——You can clean the screen with a slightly damp, lint free soft cloth.

——Do not use the device immediately while wearing gloves, when your hands are wet, or after applying hand cream.

——If you are using a phone case or plastic protective film or film on the display screen, try removing the screen protector and testing the device without them.


Open the "Map" application and double-click on each corner, then press the middle button to verify if it has zoomed in to each section.
If a certain area in other application software is affected, please note this location and try to verify the touch function of this location in the "Map" application software.


The main reason for Apple phones experiencing a situation similar to "touchscreen malfunction and jumping" is due to touchscreen malfunctions or low battery power, etc. Therefore, when we encounter this situation, the first thing we need to do is to determine the specific part of the problem based on our own judgment measures. Then, we can solve it by long pressing the power button or restarting the phone, and other basic steps. If we still cannot achieve normal use after trying this method, we can also seek help from professional maintenance personnel.

1、 Understand the difference
In the field of mobile phone repair and maintenance, the terms "original screen" and "factory screen" are often heard, which sound similar but actually have significant differences.
Original screen "refers to a screen produced by an original equipment manufacturer (OEM), which is provided by the device manufacturer and therefore has high quality and consistency. However, they may not be produced on original equipment.Original screen "refers to a screen produced by an authorized manufacturer, usually on the equipment of the manufacturer, with high quality and consistent manufacturing standards.
2、 How to choose the appropriate screen
Choosing the right screen is crucial when you need to replace your phone screen. Here are some suggestions for selecting the correct screen:
1. Get to know your phone. It is very important to understand your phone brand, model, and screen size before purchasing any phone accessories.
2. Choose a screen of appropriate quality. Choose high-quality screens, purchase from mobile phone manufacturers or authorized service centers, and ensure they provide warranty and support.
3. Identify the screen. If you are unsure whether you have obtained an original screen or a factory screen, you can observe the screen features and display quality to make a judgment. Original screens may sometimes have minor flaws or defects, while factory screens typically do not experience such issues.
3、 Summary
When it is necessary to replace the phone screen, it is particularly important to understand the difference between "original screen" and "factory screen" and choose the correct screen. Although these terms sound similar, they have different meanings and uses. Choose a high-quality screen and purchase it from a mobile phone manufacturer or authorized service center to ensure that you will receive support and warranty.

**1. OLED screen**



OLED screen, also known as organic light-emitting diode screen, is a self luminous screen that does not require a backlight source. OLED screens have advantages such as self illumination, high contrast, and vivid colors, and can also be made very thin, making them very popular in mobile phone design. However, OLED screens also have some drawbacks, such as relatively short lifespan and susceptibility to screen burn-in.

The working principle of OLED screens is to utilize the characteristic of organic materials emitting light under the action of current. When current passes through organic materials, the materials emit light, thereby achieving image display. Each pixel of an OLED screen emits light independently, allowing for high contrast and high saturation color display. Meanwhile, OLED screens also have the advantages of fast response speed and low power consumption, making them very suitable for displaying dynamic images and videos.

The advantages of OLED screens also include:

-Thin and light: OLED screens do not require a backlight and can be made very thin, making them very suitable for portable devices such as smartphones.

-High contrast: OLED screens have a very high contrast ratio, reaching 100000:1 or more, allowing them to display very deep black and bright colors.

-Wide viewing angle: OLED screens have a very wide viewing angle, reaching over 180 degrees, so the color and contrast of the image will not change when viewed from different angles.

The drawbacks of OLED screens include:

-Relatively short lifespan: The organic materials of OLED screens have a relatively short lifespan and are prone to screen burn-in, which means that when the same image is displayed for a long time, traces will be left on the screen.

-High cost: The production cost of OLED screens is relatively high, so the price is also relatively expensive.

-Insufficient brightness: OLED screens have relatively low brightness, which may make it difficult to see the screen content clearly in sunlight.



**2. LCD screen**



LCD screen, also known as liquid crystal display screen, is a type of screen that requires a backlight source. LCD screens have the advantages of low cost, high brightness, long lifespan, and also have good performance in color reproduction and contrast. However, LCD screens also have some drawbacks, such as relatively slow response speed and smaller viewing angles.

The working principle of LCD screens is to control the transmittance of light by utilizing the orientation changes of liquid crystal molecules under the action of an electric field. When an electric field acts on liquid crystal molecules, they undergo orientation changes, thereby altering the transmittance of light and achieving image display. The backlight source of LCD screens usually uses LED or CCFL (cold cathode fluorescent lamp), which can provide uniform brightness distribution.

The advantages of LCD screens include:

-Low cost: The production cost of LCD screens is relatively low, so the price is also relatively cheap.

-High brightness: LCD screens have relatively high brightness, and the screen content can be seen clearly in sunlight.

-Long lifespan: LCD screens have a relatively long lifespan and are less prone to screen burn-in.

The disadvantages of LCD screens include:

-Relatively slow response speed: LCD screens have a relatively slow response speed and may experience ghosting when displaying dynamic images.

-Small viewing angle: LCD screens have a relatively small viewing angle, and when viewed from different angles, the color and contrast of the image will change.

-Relatively low contrast: LCD screens have relatively low contrast and cannot display very deep black and bright colors.



**3. AMOLED screen**



AMOLED screen, also known as active matrix organic light-emitting diode screen, is a self luminous screen similar to OLED screen. AMOLED screens have the advantages of fast response speed, high contrast, vivid colors, and can also be made very thin, making them very popular in mobile phone design. However, AMOLED screens also have some drawbacks, such as relatively short lifespan and susceptibility to screen burn-in.

The working principle of AMOLED screens is to utilize the characteristic of organic materials emitting light under the action of current. When current passes through organic materials, the materials emit light, thereby achieving image display. Each pixel of an AMOLED screen emits light independently, allowing for high contrast and high saturation color display. Meanwhile, AMOLED screens also have the advantages of fast response speed and low power consumption, making them very suitable for displaying dynamic images and videos.

The advantages of AMOLED screens include:

-Fast response speed: AMOLED screens have a very fast response speed, reaching microsecond level, making them very smooth when displaying dynamic images.

-High contrast: AMOLED screens have a very high contrast ratio, reaching 100000:1 or more, allowing them to display very deep black and vibrant colors.

-Wide viewing angle: AMOLED screens have a very wide viewing angle, reaching over 180 degrees, so the color and contrast of the image will not change when viewed from different angles.

-Thin and light: AMOLED screens can be made very thin, making them very suitable for portable devices such as smartphones.

The drawbacks of AMOLED screens include:

-Relatively short lifespan: The organic materials of AMOLED screens have a relatively short lifespan and are prone to screen burn-in, which means that when the same image is displayed for a long time, traces will be left on the screen.

-High cost: The production cost of AMOLED screens is relatively high, so the price is also relatively expensive.

-Insufficient brightness: The brightness of AMOLED screens is relatively low, and it may be difficult to see the screen content clearly in sunlight.



**4. TFT screen**



TFT screen, also known as thin-film transistor screen, is a type of screen that requires a backlight source. TFT screens have the advantages of fast response speed, high brightness, high contrast, and also have good performance in terms of viewing angle. However, TFT screens also have some drawbacks, such as inaccurate color reproduction and smaller viewing angles.

The working principle of TFT screen is to use thin film transistors (TFT) to control the brightness of each pixel. TFT is a semiconductor device that can control the brightness of pixels by changing the current. When current passes through TFT, TFT controls the brightness of pixels, thereby achieving image display. The backlight source of TFT screens usually uses LED or CCFL (cold cathode fluorescent lamp), which can provide uniform brightness distribution.

The advantages of TFT screens include:

-Fast response speed: TFT screens have a very fast response speed, reaching the millisecond level, making them very smooth when displaying dynamic images.

-High brightness: The TFT screen has relatively high brightness, and the screen content can also be seen clearly in sunlight.

-High contrast: TFT screens have relatively high contrast and can display very deep black and bright colors.

-Wide viewing angle: TFT screens have a relatively wide viewing angle, reaching over 160 degrees, so the color and contrast of the image will not change when viewed from different angles.

The disadvantages of TFT screens include:

-Color reproduction is not accurate enough: The color reproduction of TFT screens is not accurate enough, which may result in color cast.

-High power consumption: TFT screens have relatively high power consumption, which can affect the battery life of the phone.

-High cost: The production cost of TFT screens is relatively high, so the price is also relatively expensive.

The rise of full lamination technology
The structure of a screen can be roughly divided into three parts: protective glass, touch screen, and display screen, which are arranged in sequence. To ensure the perfect presentation of the screen, it is usually necessary to perform two bonding operations: one between the protective glass and the touch screen, and the other between the display screen and the touch screen. And the film we are familiar with in daily life is actually the bonding process between the protective glass and the protective film. Although it may seem simple, it also requires exquisite bonding technology.

Screen bonding technology, according to its bonding method, is mainly divided into two categories: full bonding and frame bonding. Frame adhesive, also known as mouth glue bonding, refers to the simple fixation of the four sides of the touch screen and display screen through double-sided tape. This is the bonding method currently used by many display screens, which has the advantages of simple process and low cost. However, due to the presence of an air layer between the display screen and the touch screen, the refraction of light can affect the display effect, which is the main drawback of frame pasting technology.

Full lamination technology uses water-based adhesive or optical adhesive to completely stick the panel and touch screen together without any gaps. Compared to frame stickers, it provides a better display effect. The common full screen solutions in the market mainly come from OGS solutions from touch screen manufacturers, as well as On Cell and In Cell technology solutions led by panel manufacturers. The advantage of full lamination technology is that it eliminates the air layer between the screens, reduces the reflection between the display panel and glass, makes the screen more transparent, and thus improves the display effect of the screen. IMacs using full lamination technology can reduce reflection issues by up to 75%. In addition, full lamination technology can effectively prevent screen dust from entering and enhance the strength of the touch module. More importantly, it can significantly reduce the interference of display panel noise on touch signals.

Although full lamination technology has many advantages, its yield rate is relatively low, mainly due to the possible surface glass and panel loss during the lamination process. Therefore, controlling the defoaming and bonding yield has become the key to reducing costs.

In terms of full lamination technology, there are three main screen technologies: InCell, On Cell, and OGS. If frame pasting technology is used in the production process of mobile phone screens, it will seriously affect the display effect. And full lamination technology can significantly improve the yield rate, thereby reducing costs.



Different screen bonding technologies
In order to reduce the number of bonding cycles and improve the yield rate, several new development directions have emerged. Touch screen manufacturers mainly promote OGS/TOL solutions, while panel manufacturers are more inclined towards On Cell and In Cell technology solutions. These solutions can reduce the number of bonding times, save costs, and achieve the goal of lightweight.

In Cell technology is an innovative technique that embeds touch panel functionality into liquid crystal pixels. By embedding touch sensor functionality inside the display screen, the original three-layer structure (protective glass touch screen+display screen) has been optimized to two layers (protective glass+display screen with touch function), making the screen thinner and lighter. However, the research and development threshold for this technology is relatively high, mainly led by panel manufacturers.

Screen imaging principle
In the past, mobile phones had complex functions and rich details, but now, smartphones seem to be simplified into a single screen. We rely on this screen to operate and obtain information. The mobile phone screen displays colorful images through a combination of red, green, and blue pixels. With the development of technology, mobile phones are no longer limited to call functions, and the importance of screens has also become prominent. Whether watching videos, browsing pictures, or playing games, the screen carries the core content. Therefore, when choosing a smartphone, the screen often becomes an indispensable consideration for us.

However, are we really deep enough in our understanding of screens? When choosing a phone, we often only focus on screen size and resolution, but can these two really comprehensively measure the quality of the screen? In complex screen technology, which letter combinations truly reveal the material and panel technology of the screen? In fact, our misunderstanding of screens may be deeper than we imagine.

Unveiling the Technology and Principles of Mobile Screen

To present the text and images in our eyes, mobile phone screens rely on the three primary colors of red (R), green (G), and blue (B). Each pixel on the screen contains a complete RGB sub-pixel arrangement, and colors are recorded and expressed through RGB values. The RGB components of each pixel are within the intensity range of 0-255. It is through the different proportions of red, green, and blue that we can see a rich and colorful world.

Pixel, the color wizard of mobile phone screens

The colorful colors in our eyes are the clever combination of the three primary colors of red (R), green (G), and blue (B) on the screen. Each pixel contains a complete RGB sub-pixel arrangement, which creates a myriad of colors through different combinations of RGB values. Within the brightness range of 0-255, the proportional changes of the RGB three colors constitute the rich and colorful world in our eyes.



The comparison between 441ppi and 326ppi shows that the display effect of 441ppi on the left is more delicate and smooth.



After upgrading to 2K resolution, the screen's delicacy has reached a level that is difficult for the naked eye to distinguish. We have witnessed the continuous increase in screen resolution, which signifies that with the continuous advancement of technology, screens of the same size can now accommodate more pixels. By using PPI (pixel density) as an indicator, we can understand the number of pixels contained in each inch of the screen.

In the early days of the 1080p era of smartphones, we compared the screens of HTC Butterfly and iPhone 5, the world's first 1080p models. After capturing and zooming in on the screen with a macro lens, we found that the 441ppi HTC Butterfly surpassed the 326ppi iPhone 5 in terms of delicacy. This means that visually, the graininess on the screen is significantly reduced, and the overall display effect is more delicate and smooth. Nowadays, as mobile phone screens enter the 2K era, this level of delicacy has reached new heights, although it is still uncertain whether the naked eye can detect this change.

However, to comprehensively evaluate the quality of a mobile phone screen, relying solely on screen size and resolution is far from enough. These visible red, green, and blue small bright spots, also known as pixels, are undoubtedly the foundation, but they are only a part of screen display technology. The screen material and display technology also have a profound impact on the final visual effect.

LCD and OLED technology
In the current smartphone market, mainstream screen technologies can be divided into two categories: LCD and OLED.



LCD screens rely on backlighting during display, and light needs to pass through two layers of glass, a substrate, and various optical films, alignment films, color filters, and other components to produce polarization, which inevitably results in a loss of brightness and color. TFT, also known as thin-film transistor technology, is a key technology in LCD screens. It improves image quality by depositing a thin film as a channel area on a glass substrate.

In the TFT-LCD structure, the upper glass substrate is closely adjacent to the color filter, while the lower glass substrate is embedded with transistors. When current passes through a transistor, an electric field change is generated, causing liquid crystal molecules to deflect, thereby changing the polarization of light. Polarizers determine the brightness and darkness of pixels based on this polarity change. At the same time, the color filter attached to the upper layer of glass forms what we call RGB tri color pixels, which together constitute the colors and images displayed on the screen.



Subsequently, we will explore the types or panel technologies of LCD panels. LCD panels can be divided into two categories: simple matrix drive and active matrix drive. Among them, simple matrix driving mainly includes TN and STN technologies, while active matrix driving covers technologies such as TN, IPS, VA, and OCB. In the current smartphone market, TN and IPS technologies are more common, while VA technology is more commonly used in TV products.

TN screen, also known as Twisted Nematic (twisted nematic liquid crystal) screen, has been widely used since the emergence of liquid crystal technology and once dominated the field of electronic devices. However, nowadays many users mistakenly confuse TN screens with TFT screens, which is actually a misunderstanding of the two concepts. However, due to the mature production technology and affordable price of TN screens, they are still favored by some low-cost mobile phone brands. In addition, the high aperture ratio of TN screens makes them more energy-efficient compared to other technologies at the same brightness, and the response speed of 8-15ms is also quite fast. Therefore, although TN screens have shortcomings such as narrow viewing angles and color distortion, these advantages still make them occupy a place in the smartphone market.



IPS screen, also known as In Plane Switching (transverse electric field effect display technology), has significantly improved the color difference and narrow field of view problems of TN screens in poor viewing angles since its introduction in 1996 with its wide viewing angle technology. The electrodes of IPS liquid crystal are located in the same plane as the liquid crystal, thus achieving a wide viewing angle of 178 degrees up, down, left, and right. This breakthrough effectively overcomes the inherent defects of TN screens. However, IPS screens are not flawless. Despite its excellent viewing angle, it consumes relatively high power and has a slightly insufficient response speed, so it is necessary to weigh its pros and cons when using it.

Subsequently, in 1998, Hitachi launched an upgraded version of S-IPS (Super IPS), which not only inherited the original technological advantages of IPS, but also further optimized the response speed. In 1999, LG Philips joined the IPS camp as a joint venture, and after the bankruptcy of the joint venture in 2006, the IPS business was mainly taken over by LG Display and has continued to develop ever since.

Now, let's turn to OLED technology. OLED， The abbreviation for Organic Light Emitting Diode is different from TFT-LCD in that it has self luminescence and does not require backlight support. OLED technology has many advantages such as wide viewing angle, high contrast, low energy consumption, high reaction speed, full-color and simple process.



According to different driving methods, OLEDs can be divided into passive OLEDs (PMOLEDs) and active OLEDs (AMOLEDs). PMOLED and AMOLED are two different types. If OLED is compared to an upgraded version of LCD, then PMOLED is more similar to STN LCD, which has gradually withdrawn from the market. PMOLED performs poorly in displaying dynamic images and has a relatively slow response speed. Despite its power-saving features, it is limited in size. For smartphone users who pursue large screens and high-definition effects, PMOLED's 5-inch low resolution display is clearly not attractive enough to meet their needs. In addition, expanding the size of PMOLED will lead to an increase in pixel brightness and operating current, thereby shortening its lifespan.

Therefore, the vast majority of OLED screens we come into contact with today are AMOLED screens. AMOLED， Active matrix organic light-emitting diode, meaning active matrix organic light-emitting diode or active matrix organic light-emitting diode. The term 'AM' represents the pixel addressing technology behind it. This technology enables AMOLED to achieve low energy consumption and wide viewing angle display while maintaining high resolution and fast response, becoming one of the mainstream display technologies today. Not only smartphones, but also Samsung and LG's TV products use AMOLED screens, further proving their broad application prospects.

The core of AMOLED technology lies in its OLED matrix molecules, which can emit and store or integrate light into TFTs after electrical excitation. By precisely controlling the direction of current flowing to each pixel, AMOLED achieves high resolution and fast response. Each pixel is equipped with at least two TFTs to ensure stable control of continuous current. TFT backplane technology is crucial for AMOLED, and currently this technology has adopted two solutions: polycrystalline silicon and amorphous silicon.

The significant advantages of AMOLED include its self luminescence, wide viewing angle display, high contrast, and fast response time. In addition, compared to PMOLED, AMOLED also has a higher refresh rate, significantly reducing energy consumption. However, under direct sunlight, the reading effect of AMOLED may be affected to some extent. To improve this issue, Samsung has launched Super AMOLED technology, which enhances the display effect under strong light by reducing the screen spacing.

With the advancement of technology, Super AMOLED technology, as an upgraded version of MOLED, has the core improvement of reducing the screen spacing, which significantly improves the display effect in strong light environments. This technological innovation has significantly improved the outdoor reading experience of Super AMOLED, bringing consumers a more comfortable visual enjoyment.

1. Film application


If the phone screen is shattered without debris falling off, and the inner screen is intact, with only the outer screen damaged, it is possible to replace a non-transparent tempered film instead of repairing it. This film can cover the cracks on the outer screen of the phone screen and allow normal use. Such films are available online at a reasonable price.



II. Repair by mail



If the outer screen of a mobile phone is damaged but the inner screen is not, you can seek out repair services on online e-commerce platforms such as Taobao and Pinduoduo, and then mail the phone to the service provider for repair. This is relatively cost-effective, but the disadvantage is that the service provider may easily replace other parts or the entire phone. It is recommended to choose a shop with good reviews for repair by mail.



III. Offline maintenance



If the outer screen of the phone is severely damaged, with debris falling off, and the inner screen is also damaged, the only option is to replace the entire screen. You can go to a familiar offline repair shop for the replacement. Before going, search online for the price of a screen compatible with your phone, and then bargain. You can bargain in offline repairs, otherwise you may easily be ripped off.





IV. After-sales replacement



If you are not confident about replacing through other channels, you can directly call the official after-sales service phone number to obtain the phone number and address of the nearest official after-sales service outlet for replacement. It is important to note that after-sales service typically only provides replacements and does not offer repairs, and the prices are relatively high. If you do not mind whether it is an original screen or not, it is not recommended to replace it through after-sales service, unless it is free of charge.



Conclusion: The price of replacing a mobile phone screen varies based on different channels, and the cost and difficulty of replacement differ depending on the extent of screen damage. The four channels and methods mentioned in the article are listed in ascending order of cost. Users can choose the repair method that suits them best according to their actual situation.



In addition, it's worth noting that if your phone has been in use for a long time, replacing the screen may not be advisable. Moreover, some special types of screens, such as curved screens, can be particularly expensive. The repair cost can account for more than 30% of the price of a new model, making it unnecessary to repair.
